Naungan:
Model No: LUM
Status: Bekas
Industri Yang Berlaku: Toko Garmen, Toko Bahan Bangunan, Perusahaan periklanan
Layanan Di Luar Garansi: Dukungan teknis video, Dukungan online
Di Mana Menyediakan Layanan Lokal (di Negara Mana Terdapat Outlet Layanan Di Luar Negeri): tidak ada
Lokasi Showroom (di Negara Mana Terdapat Ruang Sampel Di Luar Negeri): tidak ada
Inspeksi Pabrik Video: Disediakan
Laporan Uji Mekanis: Disediakan
Jenis Pemasaran: Produk Biasa
Tempat Asal: Cina
Jenis: Kompresor Pendingin
Menggunakan: Suku Cadang Pendingin
Masa Garansi: 1 tahun
Sistem Layanan: Dukungan online
Advantage: 1/4 top mount freezer unit for trailer
Aplikasi: COLD ROOM
Nama Produk: water cooled
Refrigerant: R404,R22,R507
Style: MANEUROP
| Menjual unit | : | Piece/Pieces |
| Tipe paket | : | kotak kayu |
The file is encrypted. Please fill in the following information to continue accessing it
Deskripsi Produk:
Aplikasi suhu penguapan sedang dan tinggi
"Hemat energi dan
solusi hemat biaya "
Keandalan tinggi dan kepuasan pelanggan
Keandalan tinggi untuk keselamatan makanan dan barang
Dilengkapi dengan komponen Danfoss yang dioptimalkan
Bekerja bersama: Kompresor, kontrol, penukar panas.
Ini cara pintar untuk mendapatkan kinerja dan keandalan tinggi
1. Kompresor merek yang sangat dapat dipilih, Tecumseh/Copeland/Bitzer/Danfoss;
2. Kapasitas semua diproduksi;
3. Refrigeran dapat berupa R22 R404A R134A.
R22 Air didinginkan
| Model | LUM-MT018 | LUM-MT022 | LUM-MT028 | LUM-MT032 | LUM-MT036 | LUM-MT040 | LUM-MT050 | LUM-MT056 | ||
| Compressor | Model | MT018 | MT022 | MT028 | MT032 | MT036 | MT040 | MT050 | MT056 | |
| HP | 1.5 | 1.8 | 2.3 | 2.6 | 3 | 3.3 | 4.2 | 4.7 | ||
| Temperature ( ℃) | 15~25℃ | |||||||||
| Refrigerant | R22 | |||||||||
| Power Supply | 380V | |||||||||
| Condenser | Qty*Dia | 1*φ350 | 1*φ400 | 1*φ400 | 1*φ400 | 2*φ350 | 2*φ350 | 2*φ400 | 2*φ400 | |
| Air volume (m³/h) | 3110 | 3900 | 3900 | 3900 | 6220 | 6220 | 7800 | 7800 | ||
| Power of Fan(W) | 145 | 190 | 190 | 190 | 290 | 290 | 380 | 380 | ||
| Fan Voltage | 380V | |||||||||
| Compressor Capacity | Evaporating Temp 0℃ | Cooling capacity (W) | 6330 | 4560 | 6330 | 6830 | 8020 | 8780 | 10200 | 11700 |
| Power (W) | 2.11 | 1.56 | 2.11 | 2.47 | 2.76 | 3.15 | 3.54 | 4.07 | ||
| Evaporating Temp '-5℃ | Cooling capacity (W) | 5090 | 3540 | 5090 | 5440 | 6500 | 7090 | 8050 | 9380 | |
| Power (W) | 1.98 | 1.44 | 1.98 | 2.31 | 2.56 | 2.93 | 3.25 | 3.78 | ||
| Evaporating Temp -10℃ | Cooling capacity (W) | 4000 | 2670 | 4000 | 4230 | 5150 | 5590 | 6230 | 7320 | |
| Power (W) | 1.81 | 1.29 | 1.81 | 2.11 | 2.35 | 2.67 | 2.95 | 3.44 | ||
| Pipe | Suction inlet(mm) | 1/2 | 1/2 | 1/2 | 5/8 | 5/8 | 5/8 | 7/8 | 7/8 | |
| Liquid Dia (mm) | 3/8 | 3/8 | 3/8 | 1/2 | 1/2 | 1/2 | 3/4 | 3/4 | ||
| Model | LUM-MT064 | LUM-MT072 | LUM-MT080 | LUM-MT100 | LUM-MT125 | LUM-MT144 | LUM-MT 160 | ||
| Compressor | Model | MT064 | MT072 | MT080 | MT100 | MT125 | MT144 | MT160 | |
| HP | 5.3 | 6 | 6.7 | 8.3 | 10.4 | 12 | 13.3 | ||
| Temperature ( ℃) | 15~25℃ | ||||||||
| Refrigerant | R22 | ||||||||
| Power Supply | 380V | ||||||||
| Condenser | Qty*Dia | 2*φ400 | 2*φ400 | 2*φ400 | 4*φ350 | 4*φ350 | 4*φ350 | 4*φ350 | |
| Air volume (m³/h) | 7800 | 7800 | 7800 | 12440 | 12440 | 12440 | 12440 | ||
| Power of Fan(W) | 380 | 380 | 380 | 580 | 580 | 580 | 580 | ||
| Fan Voltage | 380V | ||||||||
| Compressor Capacity | Evaporating Temp 0℃ | Cooling capacity (W) | 13300 | 14600 | 16600 | 19900 | 26100 | 29600 | 32800 |
| Power (W) | 4.62 | 5.08 | 5.74 | 6.66 | 8.75 | 9.81 | 11 | ||
| Evaporating Temp '-5℃ | Cooling capacity (W) | 10500 | 11700 | 13300 | 15700 | 20800 | 23600 | 26200 | |
| Power (W) | 4.28 | 4.69 | 5.3 | 6.27 | 8.18 | 9.17 | 10.28 | ||
| Evaporating Temp -10℃ | Cooling capacity (W) | 8190 | 9130 | 10400 | 12100 | 16400 | 18500 | 20600 | |
| Power (W) | 3.89 | 4.29 | 4.84 | 5.79 | 7.55 | 8.47 | 9.49 | ||
| Pipe | Suction inlet(mm) | 7/8 | 7/8 | 1-1/8 | 1-1/8 | 1-1/8 | 1-1/8 | 1-1/8 | |
| Liquid Dia (mm) | 3/4 | 3/4 | 3/4 | 3/4 | 3/4 | 3/4 | 3/4 | ||
| R404A Air cooled | ||||||||||
| Model | LUM-MTZ018 | LUM-MTZ022 | LUM-MTZ028 | LUM-MTZ032 | LUM-MTZ036 | LUM-MTZ040 | LUM-MTZ050 | LUM-MTZ056 | ||
| Compressor | Model | MTZ018 | MTZ022 | MTZ028 | MTZ032 | MTZ036 | MTZ040 | MTZ050 | MTZ056 | |
| HP | 1.5 | 1.8 | 2.3 | 2.6 | 3 | 3.3 | 4.2 | 4.7 | ||
| Temperature ( ℃) | -30℃~10℃ | |||||||||
| Refrigerant | R404A | |||||||||
| Power Supply | 380V | |||||||||
| Condenser | Qty*Dia | 1*φ350 | 1*φ350 | 1*φ400 | 1*φ400 | 1*φ400 | 1*φ400 | 2*φ350 | 2*φ400 | |
| Air volume (m³/h) | 3110 | 3110 | 3900 | 3900 | 3900 | 3900 | 6220 | 7800 | ||
| Power of Fan(W) | 145 | 145 | 190 | 190 | 190 | 190 | 290 | 380 | ||
| Fan Voltage | 380V | |||||||||
| Compressor Capacity | Evaporating Temp 0℃ | Cooling capacity (W) | 2520 | 3440 | 4450 | 5110 | 5930 | 6700 | 8000 | 9030 |
| Power (W) | 1.31 | 1.61 | 2.14 | 2.35 | 2.81 | 3.2 | 3.9 | 4.35 | ||
| Evaporating Temp '-5℃ | Cooling capacity (W) | 1400 | 1960 | 2570 | 3030 | 3600 | 4160 | 4640 | 5280 | |
| Power (W) | 1.09 | 1.34 | 1.75 | 1.94 | 2.33 | 2.67 | 3.29 | 3.62 | ||
| Evaporating Temp -10℃ | Cooling capacity (W) | 650 | 980 | 1250 | 1580 | 1930 | 2320 | 2440 | 2640 | |
| Power (W) | 0.83 | 1.03 | 1.3 | 1.46 | 1.78 | 2.05 | 2.61 | 2.81 | ||
| Pipe | Suction inlet(mm) | 1/2 | 1/2 | 1/2 | 5/8 | 5/8 | 5/8 | 7/8 | 7/8 | |
| Liquid Dia (mm) | 3/8 | 3/8 | 3/8 | 1/2 | 1/2 | 1/2 | 3/4 | 3/4 | ||
| Model | LUM-MTZ-064 | LUM-MTZ072 | LUM-MTZ080 | LUM-MTZ100 | LUM-MTZ125 | LUM-MTZ144 | LUM-MTZ160 | ||
| Compressor | Model | MTZ064 | MTZ072 | MTZ080 | MTZ100 | MTZ125 | MTZ144 | MTZ160 | |
| HP | 5.3 | 6 | 6.7 | 8.3 | 10.4 | 12 | 13.3 | ||
| Temperature ( ℃) | -30℃~10℃ | ||||||||
| Refrigerant | R404A | ||||||||
| Power Supply | 380V | ||||||||
| Condenser | Qty*Dia | 2*φ400 | 2*φ400 | 2*φ400 | 4*φ350 | 4*φ350 | 4*φ350 | 4*φ350 | |
| Air volume (m³/h) | 7800 | 7800 | 7800 | 12440 | 12440 | 12440 | 12440 | ||
| Power of Fan(W) | 380 | 380 | 380 | 580 | 580 | 580 | 580 | ||
| Fan Voltage | 380V | ||||||||
| Compressor Capacity | Evaporating Temp 0℃ | Cooling capacity (W) | 10420 | 11680 | 13360 | 15700 | 20080 | 23380 | 25640 |
| Power (W) | 4.94 | 5.45 | 6.38 | 7.26 | 9.16 | 10.6 | 12.05 | ||
| Evaporating Temp '-5℃ | Cooling capacity (W) | 6190 | 7010 | 8080 | 9390 | 12060 | 14370 | 15790 | |
| Power (W) | 4.11 | 4.5 | 5.29 | 6.18 | 7.67 | 8.91 | 10.08 | ||
| Evaporating Temp -10℃ | Cooling capacity (W) | 3200 | 3730 | 4250 | 4930 | 6620 | 8060 | 8870 | |
| Power (W) | 3.21 | 3.52 | 4.17 | 4.8 | 6.02 | 7.05 | 7.95 | ||
| Pipe | Suction inlet(mm) | 7/8 | 7/8 | 1-1/8 | 1-1/8 | 1-1/8 | 1-1/8 | 1-1/8 | |
| Liquid Dia (mm) | 3/4 | 3/4 | 3/4 | 3/4 | 3/4 | 3/4 | 3/4 | ||
Luther-Bach Heat Exchanger Co., Ltd. Didirikan pada tahun 1990, adalah perusahaan industri yang komprehensif yang berspesialisasi dalam penelitian, pengembangan, produksi dan penjualan produk pendingin dalam pendinginan dan pendingin udara komersial dan industri.
Perusahaan kami lulus sertifikasi sistem manajemen kualitas internasional ISO9001: 2008, diidentifikasi sebagai perusahaan berteknologi tinggi pada tahun 2011, berpartisipasi dalam pengaturan dan penggunaan nasional yang tetap <> GB/T25129-2010. Setelah pemeriksaan, unit pendingin produk kami, pendingin udara, dan kondensor masing-masing mematuhi GB/T21363-2008, GB/T25129-2010, JB/T7659.4-2013, dapatkan lisensi produksi industri nasional dan sertifikasi CE.
Setelah upaya 27 tahun, produk kami memiliki reputasi yang sangat baik tidak hanya di Cina, juga di banyak negara dari Eropa, Amerika, Amerika Selatan, Asia, Samudra, Afrika dll. Tujuan kami adalah untuk menyediakan produk berkualitas baik dengan harga yang wajar, untuk memberi Anda solusi pendinginan terbaik untuk proyek Anda, untuk menjadi mitra terbaik Anda di bidang pendingin di Cina.
